● The EL series speakers are designed to deliver quality audio with a shallow basket design, ideal for boats with a limited mounting depth (1.69" / 43mm).
● They are designed to work optimally with Fusion marine amplifiers and players with custom DSP profiles for an enhanced audio experience.
● EL Series speakers are IPS65-rated, with a salt spray and UV stable design to perform and last aboard your boat.
● Classic black and white, and a new non-illuminated sport gray model now feature a black injection molded polypropylene (IMPP) cone.
● RA60 kits have also been updated with this new cone.
REVITALIZE YOUR BROWSING EXPERIENCE
● Injection molded polypropylene cone provides crisp, clear audio reproduction.
● Reduced basket design offers greater versatility during installation.
● The speakers are available in a 6.5″ design with classic and sport style grilles.
● Stable, salt and UV resistant design for harsh marine conditions.
DESIGNED AND MANUFACTURED FOR NAUTICAL ENVIRONMENTS
● EL Series loudspeakers are rated IP65 for dust and water resistance, and have demonstrated a high level of protection against salt spray and UV rays.
DESIGNED TO COMPLY WITH THE ISO12216 STANDARD
● Tested to international water ingress and pressure standards, the EL Series loudspeakers are designed and manufactured for superior quality and robustness.
QUALITY MATERIALS AND ACOUSTIC ENGINEERING
● EL Series loudspeakers incorporate high-quality materials and design elements specific to marine environments, ensuring they look and sound great on the water.
● Designed for quality acoustics.
INJECTION MOLDED POLYPROPYLENE (IMPP) CONE
● Thanks to the waterproof IMPP cone, the resistance of the speaker is improved, allowing clear and clean audio reproduction.
LIGHT VOICE COIL
● Lightweight allows for greater sensitivity, which translates into greater power and efficiency for an enhanced audio experience.
OPEN CASE CONSTRUCTION
● Streamlined open back design allows for extended power handling and versatile mounting options with reduced mounting depth.
●Enjoy a variety of colors to suit your audio.
| Color | ● Black |
| Code | 010-02080-11 |
| Dimensions | 6,93″ x 2,26″ (176 x 57,5 mm) |
| Dust and water resistance classification | IP65 |
| Configuration | full range |
| Size | 6.5" |
| Peak power (watts) | 80 vatios |
| RMS power (watts) | 20 vatios |
| Sensitivity (1 watt at 1 meter) | 91 dB |
| Frequency response | 45 Hz–16 kHz |
| Nominal impedance | 4 ohmios |
| Recommended Amplifier Power (RMS) | 20 - 40 W/canal |
| Operating temperature range | 0 - 50 °C (32 - 122 °F) |
| Nominal Voice Coil Diameter | 0.79" |
| Cone material Polypropylene | Cono de polipropileno con borde de tela |
| Compass safe distance | 254 cm (100") |
| Warranty | 1 años |
|
Mounting dimensions |
|
| Mounting Clearance Diameter | 5,12″ (130 mm) |
| Mounting Depth Clearance | 1,69″ (43 mm) |
● A pair of speakers (depending on what you select)
● 12 stainless steel Phillips mounting screws (4.2 mm x 25.4 mm [8 gauge x 1″])
● Two 6 meter (20 ft) speaker cables
● Documentation
