Nuova Rade Threaded Thru Hull
Nuova Rade Threaded Thru Hull

Nuova Rade Threaded Thru Hull

Ref.: 43491

Choose option:

1,55 €
VAT included
Select an option to see availability

Product description

Threaded polyamide (PA) skin fitting. The dimensions table lists the available variants with their code, diameter, colour, dimensions C, Ø A, Ø B and Ø D, as well as the optional hose tail and non-return valve.

Code Diameter Colour C (mm) Ø A (mm) Ø B (mm) Ø D (mm) Optional hose tail Optional non-return valve
195527 Ø 15 mm White 154 15 25 39 - -
43499 Ø 22 mm Black 155 22.7 30 39 45306 45391
43497 White
43498 Grey 45305
47756 Cream 45306
43491 Black 62 22.7 30 39 45306 45391
43489 White
43490 Grey 45305
47755 Cream 45306
43537 Ø 25 mm Black 155 25 33 39 45322 45393
43535 White
43536 Grey
43529 Black 62 25 33 39 45322
43527 White
43528 Grey
47758 Cream
196073 Black 70 25 33 39
47122 White

Technical data

  • Material: Polyamide (PA)

Dimension E by variant

VariantDimension E
15mm/Blanco/154x15x25x39148 mm
22mm/Negro/155x22.7x30x39150 mm
22mm/Blanco/155x22.7x30x39150 mm
22mm/Gris/155x22.7x30x39150 mm
22mm/Crema/155x22.7x30x39150 mm
22mm/Negro/62x22.7x30x3958 mm
22mm/Blanco/62x22.7x30x3958 mm
22mm/Crema/62x22.7x30x3958 mm
25mm/Negro/155x25x33x39150 mm
25mm/Blanco/155x25x33x39150 mm
25mm/Gris/155x25x33x39150 mm
25mm/Negro/62x25x33x3957 mm
25mm/Blanco/62x25x33x3958 mm
25mm/Gris/62x25x33x3958 mm
25mm/Crema/62x25x33x3958 mm
25mm/Negro/70x25x33x3970 mm
25mm/Blanco/70x25x33x3970 mm
