Approvals & Compliance
• CE, C-Tick, HDMI, EN 60950-1:2006, EN 60945:2002, EN 300 440-2 V1.4.1
Autopilot
• Manoeuvres / Turn Patterns: U-turn, Spiral-turn, C-turn, Zig-zag, Square-turn, Lazy S-turn, Depth contour tracking
• Steering Modes: Auto, Nav., No Drift, Follow up, Non-follow up, Turn patterns, Standby, *Wind, *Wind NAV. (*Boat type set to Sail)
Connectivity
• NMEA 0183 Sentences Supported. Input: GGA, GLL, GSA, GSV, VTG, ZDA, RMC, DBT, DPT, MTW, VLW, VHW, HDG, HDT, HDM, MWV, MWD, DSC, DSE, VDM
(AIS sentences are not bridged to/from NMEA 2000). Output: GGA, GLL, GSA, GSV, VTG, ZDA, RMC, DBT, DPT, MTW, VLW, VHW, HDG, MWV, MWD, TLL, TTM
• Bluetooth: Internal
• Ethernet: 3 × 100 Mbit/s ports (RJ-45). Adaptable to 5-pin yellow using adapter cable 000-11246-001
• N2K PGNs: Wide range of receive, transmit & receive, and transmit-only PGNs supported (full list available)
• NMEA 0183: 2 × NMEA0183 (IEC61162-1), 2 × NMEA0183-HS (IEC61162-2)
• NMEA 2000: 1 × NMEA 2000 Micro-C port, 1 LEN
• PC Connectivity: HDMI Video-in from PC
• Video: 2 × Composite video (BNC). 1 × HD video input (1080p, HDMI-A, HDCP 1.4). 1 × HD video output (1080p, HDMI-A, no HDCP)
• WiFi: Internal 802.11b/g/n
Display
• Backlight Color: White
• Resolution: 1920 × 1080
• Brightness: 1200 nits
• Size & Type: 15.6" IPS optically bonded TFT
• Viewing Angles: 80° (top/bottom), 80° (left/right)
Electrical
• Power Consumption (max): 40 W ± 4 W
• Recommended Fuse: 6 A @ 12 V DC
• Supply Voltage: 10–32 V DC
Environment
• Operating Temp: -15 °C to +55 °C (5 °F to 131 °F)
• Shock & Vibration: CE, C-Tick, HDMI, EN 60950-1:2006, EN 60945:2002, EN 300 440-2 V1.4.1
• Storage Temp: -20 °C to +60 °C (4 °F to 140 °F)
• Waterproof Rating: IPX6 (front only when panel mounted). Rear not waterproof
GPS
• Correction: N/A
• Receiver Channels: N/A
• Accuracy: N/A
• TTFF: N/A
• Update Rate: N/A
MFD
• AIS: Receive over NMEA 2000 or NMEA 0183 (not bridged to N2K)
• Autopilot: Auto, Nav., No Drift, Follow up, Non-follow up, Turn patterns, Standby, *Wind, *Wind NAV. Requires STBY button or controller with STBY button to commission
• Cartography Included: World basemap
• Cartography Supported: Insight, Navionics (Gold, NAV+ Platinum+), C-MAP (MAX N, MAX N+), NV Digital (Raster US Charts)
• Digital Switching: BEP C-Zone, Naviop
• External Storage: 1 × Micro SD slot or MI10 USB Dashmount Card Reader (2 × Micro SD slots, max 32 GB each; >32 GB requires NTFS format)
• Internal Storage: 16 GB
• GPS: External GPS required
• Multimedia: SonicHub2, Fusion Link, *Sirius (USA only), **JL Audio (**AUS & NZ only)
• Radar Compatibility: Halo, Broadband, HD Radars
• Sonar Compatibility: Requires external module or Ethernet connection to an MFD with sonar
• Weather: SiriusXM via WM-3 (USA only), GRIB
• Waypoints / Routes / Tracks: 6000 waypoints, 500 routes (100 points max per route), 50 tracks (12,000 points max per track)
• Compass Safe Distance: 50 cm (19.7")
Physical
• Dimensions (W × H × D): 400.1 × 260 × 83 mm (15.75 × 10.24 × 3.27"). With bracket: 474.9 × 307.5 × 222.5 mm (18.7 × 12.1 × 8.76")
• Mounting: Panel or bracket mount (optional heavy-duty bracket 000-13547-001)
• Weight: 3.9 kg (8.6 lbs.)
Other
• Warranty: 2 years
• Interface: Touchscreen, OP40 or OP50 controller via NMEA 2000
• Languages: Standard Pack: English (US/UK), Danish, German, Spanish, Finnish, French, Greek, Icelandic, Italian, Dutch, Norwegian, Portuguese, Swedish, Asian Pack: English (US), Japanese, Korean, Thai, Chinese, Eastern Europe Pack: English (US/UK), Bulgarian, German, Spanish, French, Hebrew, Croatian, Hungarian, Italian, Lithuanian, Latvian, Polish, Slovak, Turkish, Russia/Ukraine Pack: English (US/UK), German, Spanish, French, Italian, Russian, Ukrainian, Middle East Pack: English (US/UK), Arabic, German, Spanish, Farsi, French, Italian
